Thông số kĩ Thuật:
| Model | Refrig. | Flow-Rate | Pressure Drop | Connections | Power Supply | Dimensions [mm] | Weight | ||||
| [type] | [l/min] | [m3/h] | [scfm] | [bar] | IN-OUT [0] | [Ph/V/Fr] | A | B | C | [kg] | |
| ACT 3-T | R134.a | 350 | 21 | 12 | 0,01 | G 1/2″ | 1/230/50-60 | 345 | 420 | 740 | 28 |
| ACT 5-T | R134.a | 550 | 33 | 19 | 0,02 | G 1/2″ | 1/230/50-60 | 345 | 420 | 740 | 29 |
| ACT 8-T | R134.a | 850 | 51 | 30 | 0,04 | G 1/2″ | 1/230/50-60 | 345 | 420 | 740 | 31 |
| ACT 12-T | R134.a | 1 200 | 72 | 42 | 0,06 | G 1/2″ | 1/230/50-60 | 345 | 420 | 740 | 34 |
| ACT 18-T | R134.a | 1.800 | 108 | 64 | 0,07 | G 1″ | 1/230/50 | 485 | 455 | 825 | 39 |
| ACT 23-T | R134.a | 2.500 | 150 | 88 | 0,10 | G 1″ | 1/230/50 | 485 | 455 | 825 | 41 |
| ACT 30-T | R407C | 3.400 | 204 | 120 | 0,10 | G 1.1/4″ | 1/230/50 | 485 | 455 | 825 | 46 |
| ACT 4Ũ-T | R407C | 4.100 | 246 | 145 | 0,19 | G 1.1/4″ | 1/230/50 | 485 | 455 | 825 | 53 |
| ACT 55-T | R407C | 6.100 | 366 | 215 | 0,13 | G 1.1/2″ | 1/230/50 | 555 | 580 | 885 | 55 |
| ACT 60-T | R407C | 6.800 | 408 | 240 | 0,16 | G 1.1/2“ | 1/230/50 | 555 | 580 | 885 | 63 |
| ACT 80-T | R407C | 9.000 | 540 | 318 | 0,08 | G2″ | 1/230/50 | 555 | 625 | 975 | 92 |
| ACT100-T | R407C | 10.800 | 648 | 382 | 0.13 | G 2″ | 1/230/50 | 555 | 625 | 975 | 94 |
| ACT120-T | R407C | 12.500 | 750 | 441 | 0,08 | G 2.1/2″ | 1/230/50 | 665 | 725 | 1.105 | 141 |
| ACT 140-T | R407C | 14.500 | 870 | 512 | 0,11 | G 2.1/2″ | 1/230/50 | 665 | 725 | 1.105 | 150 |
| ACT160-T | R407C | 16.000 | 960 | 565 | 0,15 | G 2.1/2″ | 1/230/50 | 665 | 725 | 1.105 | 158 |
| ACT180-T | R407C | 18.000 | 1.080 | 636 | 0,12 | DN 80-PN 16 | 3/400/50 | 790 | 1.000 | 1.465 | 240 |
| ACT210-T | R407C | 21.000 | 1.260 | 742 | 0,18 | DN 80-PN 16 | 3/400/50 | 790 | 1.000 | 1.465 | 242 |
| ACT 250-T | R407C | 28.000 | 1.680 | 990 | 0,10 | DN 80-PN 16 | 3/400/50 | 790 | 1.000 | 1.465 | 275 |
| ACT 300-T | R407C | 34.000 | 2.040 | 1.202 | 0,17 | DN 80-PN 16 | 3/400/50 | 790 | 1.000 | 1.465 | 276 |
| ACT 360-T | R407C | 39.000 | 2.340 | 1.378 | 0,18 | DN 80-PN 16 | 3/400/50 | 790 | 1.000 | 1.465 | 311 |
| ACT 400-T | R407C | 42.000 | 2.520 | 1.484 | 0,19 | DN 100-PN 16 | 3/400/50 | 1.135 | 1.205 | 1.750 | 463 |
| ACT 500-T | R407C | 52.000 | 3.120 | 1.837 | 0,11 | DN 100-PN 16 | 3/400/50 | 1.135 | 1.205 | 1.750 | 538 |
| ACT 600-T | R407C | 63.000 | 3.780 | 2.226 | 0,19 | DN 100-PN 16 | 3/400/50 | 1.135 | 1.205 | 1.750 | 540 |
| ACT 720-T | R407C | 78.000 | 4.680 | 2.755 | 0,18 | DN 100-PN 16 | 3/400/50 | 1.135 | 1.205 | 1.750 | 612 |
| ACT 900-T | R407C | 90.000 | 5.400 | 3.178 | 0,20 | DN 150—PN 16 | 3/400/50 | 1.300 | 1.750 | 1.810 | 830 |
| ACT1100-T | R407C | 110.400 | 6.624 | 3.900 | 0,26 | DN 150-PN 16 | 3/400/50 | 1.300 | 1.750 | 1.810 | 940 |
| ACT 1200-T | R407C | 120.000 | 7.200 | 4.238 | 0,20 | DN 200-PN 16 | 3/400/50 | 1.400 | 2.200 | 1.870 | 1.055 |
| ACT 1500-T | R407C | 147.200 | 8.832 | 5.200 | 0,26 | DN 200-PN 16 | 3/400/50 | 1.400 | 2.200 | 1.870 | 1.200 |
| CORRECTION FACTOR FOR OPERATING PRESSURE CHANGES: | |||||||
| Intel air pressure barg | 4 | 5 | 6 | 7 | 8 | 10 | 12 |
| Factor | 0.77 | 0.86 | 0.93 | 1.00 | 1.05 | 1.14 | 1.21 |
